Building RAG-Powered LLM Applications with LlamaIndex Workflows

One of the primary benefits of DAG-based workflows is their flexibility and scalability. They allow for parallel execution of independent tasks, significantly improving processing speed and efficiency. It also facilitates easier maintenance and updates to the pipeline, as new tasks can be added or existing ones modified without disrupting the entire workflow. This modular approach supports iterative development and allows teams to gradually enhance their data pipelines over time. DAGs also enable better resource management, as the system can allocate computational resources more effectively based on the structure and requirements of the workflow.

However, implementing DAG-based workflows in data pipelines also comes with challenges, especially in the non-linear AI based agent development. One significant issue is the complexity of designing and managing large DAGs, especially in systems with numerous interdependent tasks. As the number of nodes and edges increases, it becomes more difficult to visualize and debug the workflow. DAGs are also acyclic in nature, meaning that they cannot implement loops if implemented in an AI application’s logic, which is not permissible in case of agentic/self-correction based approaches.

Overview of LlamaIndex Workflows

LlamaIndex announced Workflows Beta on Aug 1, 2024 which is a new method for creating complex AI applications using workflow orchestration mechanisms. This approach uses a dispatch mechanism for events to go back and forth through a collection of Python functions called steps. Each step corresponds to a component of the system which can be a simple implementation of a web page reader, vector data storage, LLM response generation, etc.

LlamaIndex Workflows

Each step in the workflow processes events and can relay events to other components as when required. Workflows in LlamaIndex are simple event-driven abstractions which can be implemented to chain multiple events. LlamaIndex workflows are automatically instrumented providing observability and explainability as well.

Building a RAG Workflow using LlamaIndex Workflows

Let us implement a simple RAG workflow using LlamaIndex Workflows.

Step 1: Install the required libraries -

• llama-index - Base library for using LlamaIndex framework
• llama-index-llms-openai - We use this library to work with OpenAI models and LlamaIndex.
• llama-index-readers-web - We will use it for reading and scraping data off a web site
• pyvis - It will be used for creating network visualizations

!pip install -U --quiet llama-index llama-index-llms-openai llama-index-readers-web pyvis

Step 2: Set up the OpenAI API key -

from google.colab import userdata
import os

os.environ["OPENAI_API_KEY"] = userdata.get("OPENAI_API_KEY")

Step 3: LlamaIndex workflows use user-defined Pydantic objects as events. The user can control the attributes and the auxiliary methods used within the event. StartEvent and StopEvent are built-in events, for our hands-on we will define a RetrieverEvent which will be used in data retrieval -

from llama_index.core.workflow import Event
from llama_index.core.schema import NodeWithScore

class RetrieverEvent(Event):
   nodes: list[NodeWithScore]

Step 4: Let us now construct the workflow and steps -

from llama_index.core import VectorStoreIndex
from llama_index.readers.web import SimpleWebPageReader
from llama_index.core.response_synthesizers import CompactAndRefine
from llama_index.core.workflow import (
   Context,
   Workflow,
   StartEvent,
   StopEvent,
   step,
)
from llama_index.llms.openai import OpenAI
from llama_index.embeddings.openai import OpenAIEmbedding

class RAGWorkflow(Workflow):

   @step(pass_context=True)
   async def ingest(self, ctx: Context, ev: StartEvent) -> StopEvent | None:
       """Entry point to ingest a document, triggered by a StartEvent with `dirname`."""
       dirname = ev.get("dirname")
       if not dirname:
           return None
       documents = SimpleWebPageReader(html_to_text=True).load_data(
           ["https://jhmhp.amegroups.org/article/view/8842/html"])
       ctx.data["index"] = VectorStoreIndex.from_documents(
           documents=documents,
           embed_model=OpenAIEmbedding(model_name="text-embedding-3-small"),
       )
       return StopEvent(result=f"Indexed {len(documents)} documents.")

   @step(pass_context=True)
   async def retrieve(
       self, ctx: Context, ev: StartEvent
   ) -> RetrieverEvent | None:
       "RAG Entry, triggered by a StartEvent with `query`."
       query = ev.get("query")
       if not query:
           return None
       print(f"Query the database with: {query}")

       # storing the query in the global context
       ctx.data["query"] = query

       # getting the index from the global context
       index = ctx.data.get("index")

       if index is None:
           print("Index is empty, load some documents before querying!")
           return None

       retriever = index.as_retriever(similarity_top_k=2)
       nodes = retriever.retrieve(query)
       print(f"Retrieved {len(nodes)} nodes.")
       return RetrieverEvent(nodes=nodes)

   @step(pass_context=True)
   async def synthesize(self, ctx: Context, ev: RetrieverEvent) -> StopEvent:
       llm = OpenAI(model="gpt-4o-mini")
       summarizer = CompactAndRefine(llm=llm, streaming=True, verbose=True)
       query = ctx.data.get("query")
       response = await summarizer.asynthesize(query, nodes=ev.nodes)
       return StopEvent(result=response)

The code above implements three primary steps consisting of function definitions holding the data ingestion from the specified web url, retrieval and synthesize processes for generating appropriate response. The system uses the workflow context to store the user query, and it specifies the event sequences for node passing and streaming the final response.

Step 5: Executing and visualizing the workflow -

from llama_index.core.workflow import (
   draw_all_possible_flows,
   draw_most_recent_execution,
)
draw_all_possible_flows(RAGWorkflow, filename="rag_flow.html")

w = RAGWorkflow()
await w.run(dirname="data")
result = await w.run(query="What is the data about?")
async for chunk in result.async_response_gen():
   print(chunk, end="", flush=True)
draw_most_recent_execution(w, filename="rag_flow_recent.html")

Output:

rag_flow.html

Query the database with: What is the data about?Retrieved 2 nodes.

The data pertains to a narrative review discussing the advancement of generative artificial intelligence in healthcare. It includes references to various articles, their citations, and options for accessing the content, such as PDF and full text. Additionally, it outlines the journal's aims and scope, as well as information for authors, reviewers, and ethical policies related to publication.

rag_flow_recent.html

Check the generated html files for the overall workflow(rag_flow.html) and the current execution flow (rag_flow_recent.html) as shown below:

rag_flow.html

rag_flow_recent.html

Final Words

Recently released LlamaIndex workflows are in beta but still pack a powerful punch when it comes to event-driven abstractions and modularity based designs in building complex AI applications. With built-in visualization and observability abilities, LlamaIndex workflows offer a promising solution in designing and building scalable and maintainable AI-driven data processing systems and pipelines.

References

1. Link to the above code
2. LlamaIndex Workflow Announcement Blog Post
3. LlamaIndex Workflows Documentation
